The AMAPACKER as a semi-automatic case packer which automatically loads cartons or bundles in one or more layers into pre-formed shipping cases placed in position by an operator. One operator can pack up to 150 boxes per minutes and at the same time all aggregation processes are done by the machine in the background.
Hicof AMAPACKER semi-automatic case packer
The AMAPACKER as a semi-automatic case packer which au¬tomatically loads cartons or bundles in one or more layers into pre-formed shipping cases placed in position by an operator. Thereby the machine follows an innovative ergonomic concept which allows effortless operation. One operator can pack up to 150 boxes per minutes and at the same time all aggregation processes are done by the machine in the background. It is the most economical way to automate the packaging process and at the same time fulfilling the legally required aggregation process.
The AMAPACKER is a completely new design, integrating robust machinery powered by high-end servo drives with the complete aggregation equipment. The machine is fully built-in stainless steel (stainless tube frame) and aluminium according highest design standards. The machine has a very small footprint and is therefore also useable for retrofitting existing packaging lines. Operation of the AMAPACKER is economical as the machine consumes only a small volume of compressed air and very few and low-cost format parts. The format change can be carried out within a very short amount of time and without tools. The machine can be equipped with a variety of infeed and outfeed options including automatic labelling and sealing of the finished shipping cases.
The AMAPACKER is a completely new design, integrating robust machinery powered by high-end servo drives with the complete aggregation equipment. The machine is fully built-in stainless steel (stainless tube frame) and aluminium according highest design standards. The machine has a very small footprint and is therefore also useable for retrofitting existing packaging lines. Operation of the AMAPACKER is economical as the machine consumes only a small volume of compressed air and very few and low-cost format parts. The format change can be carried out within a very short amount of time and without tools. The machine can be equipped with a variety of infeed and outfeed options including automatic labelling and sealing of the finished shipping cases.
- Speed up to 150 pcs/minute AMAPACKER.
- High quality materials, no painted steel.
- Changeover time < 2 Minutes possible.
- Only 3 format parts, all from stainless steel (low cost format parts).
- Software supported changeover process.
- Long lasting servo drives, worm gears and roller bearings.
- Aggregation functionality added to design (20 Mpix camera, LED flash, Thermotransfer printer).
